Maxmech MJET-100 Surface Water Pump 1HP Copper

The Maxmech MJET-100 is a 1HP (0.75kW) surface water pump, often featuring a copper winding for enhanced durability and heat resistance.

Key Features and Specifications:

• Power: 1 HP (0.75 kW)
• Motor Winding: Commonly features 100% copper winding, which is known for its better conductivity, heat dissipation, and longer lifespan compared to aluminum windings. Some sources specifically mention “Class-F copper wire” which is heat resistant up to 155°C.
• Pump Body: Often made of cast iron, sometimes with special anti-rust treatment.
• Impeller: Can be brass, stainless steel, or PPO (polyphenylene oxide).
• Shaft: AISI 304 stainless steel is a common material for the pump shaft.
• Max. Head: Around 50-60 meters, indicating the maximum vertical distance the pump can push water.
• Max. Flow Rate: Typically around 50 L/min (3.6 m³/h).
• Max. Suction Lift: Around 7-8 meters, which is the maximum vertical distance the pump can draw water from.
• Inlet/Outlet: Usually 1″x1″.
• Motor Speed: Around 2900 rpm.
• Voltage: Single phase, 220V/240V.
• Protection: Often includes a built-in thermal protector for single-phase motors. Insulation class F and protection class IP44 are common.
• Applications: Ideal for domestic water supply boosting, small-scale commercial water transfer, irrigation systems, and garden watering.
