Key Specifications and Features
| Specification | Value (Approximate) | Note on Performance |
| Power Rating | 400 Watts (W) | The power consumed by the pump motor. |
| Maximum Head (Lift) | 50 Meters (M) | The maximum vertical height it can push water (e.g., from a 50m deep borehole). The flow rate will be highest at shallow depths and will decrease as the lift approaches 50m. |
| Flow Rate (Capacity) | 3,000 Liters/Hour (3 m³/h) OR 1,500 Liters/Hour (1.5 m³/h) | This varies depending on the specific model variation and the actual lift. A typical figure for a 50m head is closer to 1.5 m³/h. |
| Voltage | 24V DC or 48V DC | Requires a set of solar panels wired to match the pump’s voltage requirements. |
| Required Solar Power | Typically 400W (e.g., two 200W panels) | The panels are directly connected to the pump for it to run during the day. |
| Outlet Size | 1 inch (25mm) | Standard connection size for the piping. |
